About CNC MACHINING

CNC machining is a process used in manufacturing that involves the use of computers to control machine tools. The most common machine shop tools that can be controlled in this manner are lathes and milling machines.

CNC stands for Computer Numerical Control. The machine tool reads the part program that can either be programmed at the machine or more typically offline using CAD and CAM software programs.

Software packages we use to create machine programs:

Computer Aided Design (CAD) - Solidworks®

Computer Aided Manufacturing (CAM) - Mastercam®

CNC TURNING

CNC turning typically involves machining parts that are round in shape such as a washer Machining America Inc CNC lathes take turning several steps further. With live tooling, a Y axis, and a sub spindle Machining America Inc has the ability to machine parts on our lathes that would normally be restricted to run on a milling machine.

Typical materials we machine on our lathes are stainless steel, brass, aluminum, phenolic, and many types of plastics including UHMW, Teflon™, ABS, PET, and Acetal.

6-inch Diameter Aluminum

6-inch Diameter Aluminum

Lathe Parts In Production

Lathe Parts In Production

Stainless Steel Parts

Stainless Steel Parts

304 ss hex

304 ss hex

Lathe Parts

Lathe Parts

previous arrow
next arrow

CNC MILLING

At Machining America Inc. we have 2 different types of milling machines. The first type is the typical 3-axis vertical milling machine. The spindle is oriented perpendicular to the floor and travels in the X, Y, and Z directions.

The second type of milling machine is what is commonly known as a horizontal. The spindle is oriented parallel to the floor and travels in the X, Y, and Z directions plus a full fourth axis known as the B axis. A couple of the benefits of a horizontal machining center include easy chip evacuation, multiple sides of a part can be machined in a single setup, and high production can be achieved utilizing the dual pallet system.

Typical Milled Housings

Typical Milled Housings

18 x 24 inch Plaque

18 x 24 inch Plaque

Typical Housing Covers

Typical Housing Covers

Typical Housings and Covers

Typical Housings and Covers

Engraving

Engraving

Housing

Housing

Covers

Covers

previous arrow
next arrow

CNC MACHINING EQUIPMENT

CLOSE ACCORDION

CNC Turning Machines

1 – 2007 Mori Seiki NL2500SY 700

  • 6000 RPM
  • Y-Axis
  • Live Tooling on all turret stations
  • Full C axis
  • 12 tool stations
  • 3.1” bar capacity
  • Chip conveyor

1 – 2005 Mori Seiki NL2000SY 500
  • 6000 RPM
  • Y-Axis
  • Live Tooling on all turret stations
  • 12 tool stations
  • 1.75” bar capacity

CNC Vertical Milling Machines

1 – 2019 Doosan DNM 4000

  • 1,889 IPM X/Y/Z rapids
  • 20 Tool Magazine
  • 24,000 RPM Spindle
  • LNS Conveyor
  • Renishaw OTS-AA Tool Setter

1 – 2016 DMG MORI MILLTAP700

  • 0.9 second tool change times
  • Chip-to-chip times under 1.5 seconds
  • 24,000 RPM Spindle

1 – 2015 DMG MORI MILLTAP700

  • 0.9 second tool change times
  • Chip-to-chip times under 1.5 seconds
  • 24,000 RPM Spindle

4 – 2013 DMG MORI MILLTAP700

  • 0.9 second tool change times
  • Chip-to-chip times under 1.5 seconds
  • 24,000 RPM Spindle

1 – 2010 Mori Seiki NV5000

  • 20,000 RPM Spindle
  • 30 Tool magazine
  • JV40 Chip blaster high pressure coolant
  • LNS chip conveyor

1 – 2006 Mori Seiki Dura Vertical 5100

  • 10,000 RPM Spindle
  • 30 Tool magazine
  • Chip conveyor

1 – 1995 Excel PMC5VT20

  • 6,000 RPM Spindle
  • 20 + 1 Tool magazine
  • Fanuc OM Control

CNC Horizontal Milling Machines

1 – 2006 Mori Seiki NH5000

  • 14,000 RPM Spindle
  • 60 Tool magazine
  • 2 Pallet
  • Travels Z 28.7” x X 28.7” x Y 33.5”

1 – 2016 DMG MORI MILLTAP700

  • 0.9 second tool change times
  • Chip-to-chip times under 1.5 seconds
  • 24,000 RPM Spindle

CNC Band Saw and Manual Saws

1 – DoAll DC-330NC Continental Series Automatic Band Saw

  • PLC control
  • Single column rise/fall
  • 72-390 FPM cutting speed
  • Round capacity 13”
  • Rectangle 15.75” x 13”

1 – Dake Johnson V-40 Vertical Band Saw
  • 41 inch Throat Depth
  • 50-500 FPM

1 – Dake MEP Circular Cold Saw

  • 14 inch Blade
  • 20/40 RPM
  • Air vise

1 – Holz-Her 1203 Vertical Panel Saw

  • 5.0’x 10.0’ Travel
  • 9.0” Carbide Blade
  • Vacuum Assisted Chip Extraction

Inspection Equipment

1 – 2019 Keyence Instant Measurement System

  • Measures 99 critical dimensions in 3 seconds
  • Offline Editor Software
  • NIST Certificates and traceability records

1 – 2008 Zeiss CMM Contura G2

  • Granite base
  • VAST XXT probe system
  • X axis bridge travel 39”
  • Y axis travel 47”
  • Calypso Software

1 – 45X Zoom Stereo Microscope

  • Trinocular Head
  • Focus Block for V3 Base, 76mm Ring
  • 80 LED Ring Light, Variable Intensity
  • Reticle, 25mm Cross Linear

Support Equipment

2 – 2016 MINI 9 Dry Deburring and Finishing Machine

  • 9” x 48” abrasive belt
  • 4” maximum part thickness
  • Dust Collection

1 – Omega Sonics Pro Plus Ultrasonic Cleaner
1 – Burr Bench Vibratory Deburring 15” x 19” Tub
1 – Wysong 36” Metal Shear
1 – Tennsmith 52” Metal Shear
1 – ThermoGrip Tool Heat Shrink Unit
1 – Barrett Spintech Chip Spinner
